SmartDNS is a local DNS server. SmartDNS accepts DNS query requests from local clients, obtains DNS query results from multiple upstream DNS servers, and returns the fastest access results to clients.
Avoiding DNS pollution and improving network access speed, supports high-performance ad filtering.
Unlike dnsmasq's all-servers, smartdns returns the fastest access resolution.

Support Raspberry Pi, openwrt, ASUS router and other devices.

Software Show

Ali DNS
Use Ali DNS to query Baidu's IP and test the results.

pi@raspberrypi:~/code/smartdns_build $ nslookup www.baidu.com 223.5.5.5
Server:         223.5.5.5
Address:        223.5.5.5#53

Non-authoritative answer:
www.baidu.com   canonical name = www.a.shifen.com.
Name:   www.a.shifen.com
Address: 180.97.33.108
Name:   www.a.shifen.com
Address: 180.97.33.107

pi@raspberrypi:~/code/smartdns_build $ ping 180.97.33.107 -c 2
PING 180.97.33.107 (180.97.33.107) 56(84) bytes of data.
64 bytes from 180.97.33.107: icmp_seq=1 ttl=55 time=24.3 ms
64 bytes from 180.97.33.107: icmp_seq=2 ttl=55 time=24.2 ms

--- 180.97.33.107 ping statistics ---
2 packets transmitted, 2 received, 0% packet loss, time 1001ms
rtt min/avg/max/mdev = 24.275/24.327/24.380/0.164 ms
pi@raspberrypi:~/code/smartdns_build $ ping 180.97.33.108 -c 2
PING 180.97.33.108 (180.97.33.108) 56(84) bytes of data.
64 bytes from 180.97.33.108: icmp_seq=1 ttl=55 time=31.1 ms
64 bytes from 180.97.33.108: icmp_seq=2 ttl=55 time=31.0 ms

--- 180.97.33.108 ping statistics ---
2 packets transmitted, 2 received, 0% packet loss, time 1001ms
rtt min/avg/max/mdev = 31.014/31.094/31.175/0.193 ms

smartdns
Use SmartDNS to query Baidu IP and test the results.

pi@raspberrypi:~/code/smartdns_build $ nslookup www.baidu.com
Server:         192.168.1.1
Address:        192.168.1.1#53

Non-authoritative answer:
www.baidu.com   canonical name = www.a.shifen.com.
Name:   www.a.shifen.com
Address: 14.215.177.39

pi@raspberrypi:~/code/smartdns_build $ ping 14.215.177.39 -c 2
PING 14.215.177.39 (14.215.177.39) 56(84) bytes of data.
64 bytes from 14.215.177.39: icmp_seq=1 ttl=56 time=6.31 ms
64 bytes from 14.215.177.39: icmp_seq=2 ttl=56 time=5.95 ms

--- 14.215.177.39 ping statistics ---
2 packets transmitted, 2 received, 0% packet loss, time 1001ms
rtt min/avg/max/mdev = 5.954/6.133/6.313/0.195 ms

From the comparison, smartdns found the fastest IP address to visit www.baidu.com, so accessing Baidu's DNS is 5 times faster than Ali DNS.

Features

Multiple upstream DNS servers
Support configuring multiple upstream DNS servers and query at the same time.the query will not be affected, Even if there is a DNS server exception.
Return the fastest IP address
Supports finding the fastest access IP address from the IP address list of the domain name and returning it to the client to avoid DNS pollution and improve network access speed.
Support non-standard ports
Support non-53 port query, support TCP query, effectively avoid DNS pollution.
Domain IP address specification
Support configuring IP address of specific domain to achieve the effect of advertising filtering, and avoid malicious websites.
Domain name high performance rule filtering
Support domain name suffix matching mode, simplify filtering configuration, filter 200,000 recording and take time <1ms.
Linux multi-platform support
Support standard Linux system (Raspberry Pi), openwrt system various firmware, ASUS router native firmware.
Support IPV4, IPV6 dual stack
Support IPV4, IPV6 network, support query A, AAAA record.
High performance, low resource consumption
Multi-threaded asynchronous IO mode, cache cache query results.

Architecture

SmartDNS receives DNS query requests from local network devices, such as PCs and mobile phone query requests.
SmartDNS sends query requests to multiple upstream DNS servers, using standard UDP queries, non-standard port UDP queries, and TCP queries.
The upstream DNS server returns a list of Server IP addresses corresponding to the domain name. SmartDNS detects the fastest Server IP with local network access.
Return the fastest accessed Server IP to the local client.

Usage

Download the package

Download the matching version of the SmartDNS installation package. The corresponding installation package is as follows.

system	package	Description
Standard Linux system (Raspberry Pi)	smartdns.xxxxxxxx.armhf.deb	Support Raspberry Pi Raspbian stretch, Debian 9 system.
Standard Linux system (x86_64)	smartdns.xxxxxxxx.x86_64..tar.gz	Support for x86_64 systems.
ASUS native firmware (optware)	smartdns.xxxxxxx.mipsbig.ipk	Systems that support the MIPS big-end architecture, such as RT-AC55U, RT-AC66U.
ASUS native firmware (optware)	smartdns.xxxxxxx.mipsel.ipk	System that supports the MIPS little endian architecture, such as the RT-AC68U.
ASUS native firmware (optware)	smartdns.xxxxxxx.arm.ipk	System that supports the ARM small endian architecture, such as the RT-AC88U.
openwrt 15.01	smartdns.xxxxxxxx.ar71xx.ipk	Support AR71XX MIPS system.
openwrt 15.01	smartdns.xxxxxxxx.ramips_24kec.ipk	Support small-end routers such as MT762X
openwrt 15.01(Pandora)	smartdns.xxxxxxxx.mipsel_24kec_dsp.ipk	Support for Pandora firmware of MT7620 series
openwrt LEDE	smartdns.xxxxxxxx.mips_24kc.ipk	Support AR71XX MIPS system.
openwrt LEDE	smartdns.xxxxxxxx.mipsel_24kc.ipk	Support small-end routers such as MT726X
openwrt LEDE	smartdns.xxxxxxxx.x86_64.ipk	Support x86_64 router
openwrt LEDE	smartdns.xxxxxxxxxxx.arm_cortex-a9.ipk	Router supporting arm A9 core CPU
openwrt LEDE	smartdns.xxxxxxxxx.arm_cortex-a7_neon-vfpv4.ipk	Router supporting arm A7 core CPU
openwrt LUCI	luci-app-smartdns.xxxxxxxxx.xxxx.all.ipk	Openwrt management interface

The openwrt system supports a lot of CPU architecture. The above table does not list all the supported systems. Please check the CPU architecture and download it.
The merlin Merlin firmware theory is the same as the ASUS firmware, so install the corresponding ipk package according to the hardware type. (Merlin is not verified yet, and has a problem to submit an issue)
The CPU architecture can be found in the router management interface:
Log in to the router, click System->Software, click the Configuration tab page, and find the corresponding software architecture in the opkg installation source. The download path can be found, as follows, the architecture is ar71xx
```
src/gz chaos_calmer_base http://downloads.openwrt.org/chaos_calmer/15.05/ar71xx/generic/packages/base
```
Please download it from the Release page: Download here

Standard Linux system installation (Raspberry Pi, X86_64 system)

Installation

Download the installation package like smartdns.xxxxxxxx.armhf.deb and upload it to the Linux system. Run the following command to install
```
dpkg -i smartdns.xxxxxxxx.armhf.deb
```
Configuration

After the installation is complete, you can configure the upstream server to smartdns. Refer to the Configuration Parameters for specific configuration parameters.
In general, you only need to add server [IP]:port, server-tcp [IP]:port configuration items.
Configure as many upstream DNS servers as possible, including servers at home and abroad. Please refer to the Configuration Parameters section for configuration parameters.
```
vi /etc/smartdns/smartdns.conf
```

Start Service

systemctl enable smartdns
systemctl start smartdns

Forwarding DNS request to SmartDNS

Modify the DNS server of the local router and configure the DNS server as SmartDNS.
- Log in to the router on the local network and configure the Raspberry Pi to assign a static IP address.
- Modify the WAN port or DHCP DNS to the Raspberry Pi IP address. Note: I. Each router configuration method is different. Please search Baidu for related configuration methods. II. some routers may not support configuring custom DNS server. in this case, please modify the PC's, mobile phone's DNS server to the ip of Raspberry Pi.

Check if the service is configured successfully

Query domain name with nslookup -querytype=ptr 127.0.0.1
Check if the name item in the command result is displayed as smartdns or hostname, such as smartdns

pi@raspberrypi:~/code/smartdns_build $ nslookup -querytype=ptr 127.0.0.1
Server:         192.168.1.1
Address:        192.168.1.1#53

Non-authoritative answer:
1.0.0.127.in-addr.arpa  name = smartdns.

openwrt/LEDE

Installation

Upload the software to the /root directory of the router with winscp or other tool, and execute the following command to install it.
```
opkg install smartdns.xxxxxxxx.xxxx.ipk
opkg install luci-app-smartdns.xxxxxxxx.xxxx.all.ipk
```
Configuration

Log in to the openwrt management page and open Services->SmartDNS to configure SmartDNS.
- Add upstream DNS server configuration to Upstream Servers. It is recommended to configure multiple DNS servers at home and abroad.
- Specify the IP address of a specific domain name in Domain Address, which can be used for ad blocking.
Start Service

There are two ways to use the SmartDNS service, one is directly as the primary DNS service, the other is as the upstream of dnsmasq.
By default, SmartDNS uses the first method. You can choose according to your needs in the following two ways.
Method 1: SmartDNS as primary DNS Server (default scheme)
- Enable SmartDNS port 53 port redirection

  Log in to the router, click on Services->SmartDNS, check the Redirect option to enable port 53 forwarding.
- Check if the service is configured successfully

  Query domain name with nslookup -querytype=ptr 127.0.0.1 See if the name item in the command result is displayed as smartdns or hostname, such as smartdns
```
pi@raspberrypi:~/code/smartdns_build $ nslookup -querytype=ptr 127.0.0.1
Server:         192.168.1.1
Address:        192.168.1.1#53

Non-authoritative answer:
1.0.0.127.in-addr.arpa  name = smartdns.
```
- The interface prompts that the redirect failed
  - Check if iptable, ip6table command is installed correctly.
  - The openwrt 15.01 system does not support IPV6 redirection. If the network needs to support IPV6, please change DNSMASQ upstream to smartdns, or change the smartdns port to 53, and disable dnsmasq.
  - After LEDE system, please install IPV6 nat forwarding driver. Click system->Software, click update lists to update the software list, install ip6tables-mod-nat
  - Use the following command to check whether the routing rule takes effect.
```
iptables -t nat -L PREROUTING | grep REDIRECT
```
  - If the forwarding function is abnormal, please use Method 2: As the upstream of DNSMASQ.
Method 2: SmartDNS as upstream DNS Server of DNSMASQ
- Disable SmartDNS port 53 port redirection

  Log in to the router, click on Services->SmartDNS, uncheck the Redirect option to disable port 53 forwarding.
- Forward dnsmasq's request to SmartDNS

  Log in to the router, click Network->DHCP and DNS, and modify DNS forwardings to:
```
/#/127.0.0.1#5353
```
  Where #5353 is the service port number of smartdns. If it is not modified, the default is 5353.
- Check if the service is configured successfully

  Use nslookup to query the www.baidu.com domain name to see if the IP address of Baidu in the result is `only one. If there are multiple IP addresses returned, it means that it is not valid. Please try to check several domain names.
```
pi@raspberrypi:~ $ nslookup www.baidu.com 192.168.1.1
Server:         192.168.1.1
Address:        192.168.1.1#53

Non-authoritative answer:
www.baidu.com   canonical name = www.a.shifen.com.
Name:   www.a.shifen.com
Address: 14.215.177.38
```
Start Service

Check the `Enable' in the configuration page to start SmartDNS server.
Note
- If chinaDNS is already installed, it is recommended to configure the upstream of chinaDNS as SmartDNS.
- SmartDNS defaults to forwarding port 53 requests to the local port of SmartDNS, controlled by the Redirect configuration option.

ASUS router native firmware / Merlin firmware

Note: Merlin firmware is derived from ASUS firmware and can theoretically be used directly with the ASUS package. However, it is currently unverified. If you have any questions, please submit an issue.

Prepare

When using this software, you need to confirm whether the router supports U disk and prepare a USB disk.
Enable SSH login

Log in to the management interface, click System Management-> Click System Settings and configure Enable SSH to Lan Only.
The SSH login username and password are the same as the management interface.
Insstall Download Master

In the management interface, click USB related application-> click Download Master to download.
After the download is complete, enable Download Master. If you do not need the download function, you can uninstall Download Master here, but make sure that Download Master is enabled before uninstalling.
Install SmartDNS

Upload the software to the router's /tmp/mnt/sda1 directory using winscp. (or copy the network neighborhood to the sda1 shared directory)
```
ipkg install smartdns.xxxxxxx.mipsbig.ipk
```

Restart router

After the router is started, use nslookup -querytype=ptr 127.0.0.1 to query the domain name.
See if the name item in the command result is displayed as smartdns or hostname, such as smartdns

pi@raspberrypi:~/code/smartdns_build $ nslookup -querytype=ptr 127.0.0.1
Server:         192.168.1.1
Address:        192.168.1.1#53

Non-authoritative answer:
1.0.0.127.in-addr.arpa  name = smartdns.

Note

In the above process, smartdns will be installed to the root directory of the U disk and run in optware mode.
Its directory structure is as follows: (only smartdns related files are listed here)

USB DISK
└── asusware.mipsbig
        ├── bin
        ├── etc
        |    ├── smartdns
        |    |     └── smartdns.conf
        |    └── init.d
        |          └── S50smartdns
        ├── lib
        ├── sbin
        ├── usr
        |    └── sbin
        |          └── smartdns
        ....

To modify the configuration, you can use ssh to login to the router and use the vi command to modify it.

vi /opt/etc/smartdns/smartdns.conf

It can also be modified from Network Neighborhood. From the neighbor sharing directory sda1 you can't see the asusware.mipsbig directory, but you can directly enter asusware.mipsbig\etc\init.d in File Manager to modify it.

\\192.168.1.1\sda1\asusware.mipsbig\etc\init.d

Configuration parameter

parameter	Parameter function	Default value	Value type	Example
server-name	DNS name	host name/smartdns	any string like hosname	server-name smartdns
bind	DNS bind port	[::]:53	IP:PORT	bind 192.168.1.1:53
cache-size	Domain name result cache number	512	integer	cache-size 512
rr-ttl	Domain name TTL	Remote query result	number greater than 0	rr-ttl 600
rr-ttl-min	Domain name Minimum TTL	Remote query result	number greater than 0	rr-ttl-min 60
rr-ttl-max	Domain name Maximum TTL	Remote query result	number greater than 0	rr-ttl-max 600
log-level	log level	error	error,warn,info,debug	log-level error
log-file	log path	/var/log/smartdns.log	File Pah	log-file /var/log/smartdns.log
log-size	log size	128K	number+K,M,G	log-size 128K
log-num	archived log number	2	Integer	log-num 2
conf-file	additional conf file	None	File path	conf-file /etc/smartdns/smartdns.more.conf
server	Upstream UDP DNS server	None	[ip][:port], Repeatable	server 8.8.8.8:53
server-tcp	Upstream TCP DNS server	None	[IP][:port], Repeatable	server-tcp 8.8.8.8:53
address	Domain IP address	None	address /domain/ip	address /www.example.com/1.2.3.4
bogus-nxdomain	bogus IP address	None	[IP]，Repeatable	bogus-nxdomain 1.2.3.4

Donate

If you feel that this project is helpful to you, please donate to us so that the project can continue to develop and be more perfect.

PayPal

Alipay

Wechat

Statement

SmartDNS copyright belongs to Nick Peng (pymumu at gmail.com).
SmartDNS is free software, users can copy and use SmartDNS non-commercially.
It is forbidden to use SmartDNS for commercial purposes.
The use of the software is at the user's own risk and, to the fullest extent permitted by applicable law, damages and risks resulting from the use of this product, including but not limited to direct or indirect personal damage, loss of commercial profit, trade disruption No loss of business information or any other financial loss.
This software does not collect any user information without the user's consent.

Additional information

Currently the code is not open source, and subsequent open source according to the situation.

Languages

C 73.5%

C++ 15%

Shell 5.1%

JavaScript 2.9%

Lua 2.6%

Other 0.8%

ReadMe.md Unescape Escape

SmartDNS
